Description
Combo includes:
- CL0508 (TORQ CL0508 Micro HV Servo) * 3pcs
- CL0604T (TORQ CL0604T Mini HV Rudder Helicopter Servo) * 1pcs
Recommended for helicopter sized 380-420 (main blade length: 380-420mm)
I. CL0508 (TORQ CL0508 Micro HV Servo)
1. Features:
– Engineered for High Performance Aircraft Extremes
– Specifically Designed for Helicopter, Airplane or Jet Based Applications
– Massive Levels of Torque & Speed
– Ultra Precise, High Resolution Precision
– Coreless Motor Design for Optimized High Torque Output
– Fully Replaceable Steel Gear Train for Maximum Strength
– Excellent Thermal Dissipation via 6061 Aircraft Aluminum Case
– 8.4V High Voltage Ready
– Dual Ball Bearing Design
Torque:
6.20Kg.cm (86.10 oz. in.) @ 8.4V
5.20Kg.cm (72.21 oz. in.) @ 7.4V
4.20Kg.cm (58.32 oz. in) @ 6.0V
Transit Speed:
0.07 sec. @ 8.4V
0.08 sec. @ 7.4V
0.09 sec. @ 6.0V
2. Specifications:
Dimensions: 23x12x27.5mm (LxWxH)
Weight: 20g
Operating Voltage: 4.8V – 8.4V DC
Working Pulse Width / Frequency: 1520us / 333Hz or 760us / 560Hz (need the TBOX Program Card)
II. CL0604T (TORQ CL0604T Mini HV Rudder Helicopter Servo):
1. Features:
– Dedicated Helicopter Rudder Servo
– Incredible Levels of Speed & Performance
– Ultra Precise, High Resolution Control
– Coreless Motor Design for Peak Torque Demand
– Fully Replaceable Steel Gear Train for Maximum Strength
– Excellent Thermal Dissipation via 6061 Finned Aluminum Case
– 8.4V High Voltage Ready
– Optimized for High Demand Rudder Control
– Dual Ball Bearing Construction
Speed:
0.04 sec / 60° @ 8.4V
0.06 sec / 60° @ 6.0V
Torque:
6Kg.cm / 83.32 oz. in. @ 8.4V
4Kg.cm / 55.54 oz. in. @ 6.0V
2. Specifications:
Motor Type: Coreless Motor
Servo Arm Type: Futaba
Working Pulse Width / Frequency: 760us / 560Hz
Weight: 40g
Dimensions: 35.5mm x 15mm x 32.7mm (LxWxH)
Voltage Range: 6.0V – 8.4V
Usage Note:
For helicopter rudder usage only. Please note that the TORQ CL0604T Mini HV Rudder Helicopter Servo servo must be connected to a flybarless flight controller that is set at a 760us pulse width setting for proper functionality. Due to the 760us pulse width, if the servo is connected to a receiver or servo tester, the servo will not properly function due to these applications that use a 1520us pulse width.
Servo Grommet is suggested use if you use our servo on Nitro Heli.
