Tiger Motor U7 420kv U-Power Professional Motor V2.0
The U7 series motor by Tiger Motors is the ultimate heavy-lift multi-rotor motor. This motor shines in efficiency and quality, giving you the longest flight times possible.
This motor is designed for large scale multi-rotor platforms looking to lift DSLR sized gear. A 17″-18″ prop is recommended to fly with this motor supporting 6s battery voltage.
Specifications
- KV………………………………………………………………………………………………….420
- Internal resistance……………………………………………………………………….33mΩ
- Max. efficiency current…………………………………………………….(10-21A)>83%
- Max Continuous Power(W)180S……………………………………………….1180W
- Max Continuous current(A)180S…………………………………………………….40A
- No.of Cells(Lipo)…………………………………………………………………………..3-8S
- ldle current(10)@10v(A)………………………………………………………………..0.9A
- Weight(g)……………………………………………………………………………………..255g
- Motor Dimension(Dia.*Len)………………………………………..Φ60.7×39.5mm
- Shaft Diameter…………………………………………………………………………….4mm
- Configuration…………………………………………………………………………..12N14P
