Description

iFlight Chimera-9 Frame Kit for Long range FPV.

:

The iFlight Chimera-9 is a 9″ long-range frame designed to give maximum stability and flight time during your cinematic shoots!

Highlights:

Specially Designed Heatsink for DJI O3 Air Unit

New Camera Mount for a wider camera FOV with TPU damping inserts

New Side Panels to perfectly fit the O3 Air Unit in the back

New Dual 5.8G VTX Antenna TPU mount

Latest Chimera9 Frame Upgrades for Maximum Protection

Specifications:

Product Name：Chimera9 Frame Kit

Geometry: DeadCat (DC)

Wheelbase: 405mm

Frame Dimension: L360*W235*H34 mm

Frame Body Dimension: 34mm

Arm Thickness: 6mm

Bottom Plate Thickness: 3mm

Top Plate Thickness: 2mm

Upper Plate Thickness: 3mm

Motor Mounting: 16x16mm / 19*19mm

VTX Mounting: 30.5*30.5 φ3mm / 25*25 φ1.6mm / 20*20 φ2mm

Weight: 385.5grams

Packing List:

1 x Chimera9 Frame Kit

1x O3 Air Unit Heatsink

1x O3 MIPI Digital Video Cable 215mm

2x O3 IPEX to RP-SMA Antenna Pigtails

1 x O3 Dual Antenna TPU

1 x Screw Bag

1 x TPU Set

2 x Anti-Slip Battery Pad

2 x Battery Strap (20*300mm)
